| LENGTH less boom | 4 930 mm |
| WIDTH | 3 388 mm |
| HEIGHT | 3 330 mm |
| GROUND CLEARANCE | 710 mm |
| WEIGHT less attachment | 28 350 kg |
| TAIL SWING RADIUS | 2095 mm |
| ENGINE Stage V | Tigercat FPT N67 Stage V 217 kW (291 hp) @ 2,200 rpm (rated) |
| ENGINE Tier 4f | Tigercat FPT N67 Tier 4f 212 kW (284 hp) @ 2,200 rpm (rated) |
| ENGINE Non-certified | Tigercat FPT N67 Non-Certified 212 kW (284 hp) @ 2,200 rpm (rated) |
| AIR FILTRATION | Precleaner and 2-stage engine air cleaner |
| COOLING | Aluminum side-by-side radiator, oil cooler, charge air cooler Removable intake debris screen |
| FAN | Hydraulically driven, automatic variable speed, reversible |
| FUEL CAPACITY | 585 L |
| DEF CAPACITY | 80 L |
| LOW RANGE | 1,9 km/h |
| HIGH RANGE | 4,2 km/h |
| PUMP, MAIN | Piston |
| PUMP, HARVESTING HEAD | Piston |
| PUMP, COOLING FAN | Piston |
| PUMP, CASE | Gear |
| FILTRATION | (5) Spin-on, 7 micron full flow (1) water absorbing |
| CYLINDERS, HOIST | 140 mm (5.5 in) bore |
| CYLINDERS, STICK/ER | (2) 110 mm (4.3 in) bore |
| HORSEPOWER CONTROL | Electronic speed sensing All-speed antistall |
| RESERVOIR | 204 L |
| TRACK FRAMES | R6-152-5 heavy-duty forestry Integral track guides/ramp angles |
| TRACK CHAIN | F8/D6D 203 mm (8 in) pitch sealed and greased |
| FINAL DRIVE | (2) Axial piston motors Infinitely variable speed |
| TRACTIVE EFFORT | 280 kN |
| GEARBOX | Triple reduction planetary type with brake |
| FRONT IDLER | Hydraulic track adjuster Spring shock absorber |
| ROLLERS, LOWER | (9) D6 single/double flange tractor type |
| SLIDES, UPPER | Replaceable, bolt-on Optional rollers |
| TRACK SHOE | 610 mm (24 in) single/double grouser |
| Optional | 610 mm (24 in) double grouser 710 mm (28 in) double grouser 710 mm (28 in) single grouser tri-track 760 mm (30 in) double grouser tri-track 915 mm (36 in) triple grouser tri-track |
13 July 2022
Jessica Mann, product designer for the Tigercat tracked harvesting products takes us on a walk-around of the 822E and LX830E carriers. Watch this video to learn about the key features and benefits of owning a Tigercat 822E or LX830E compact tail-swing machine.
