Product Specifications

Metric
Imperial

Dimensions

LENGTH less boom 5 380 mm
WIDTH 3 380 mm
HEIGHT 3 290 mm
GROUND CLEARANCE 710 mm
WEIGHT less attachment 30 840 kg
TAIL SWING RADIUS 3 075 mm

Power

ENGINE Tier 4f Tigercat FPT N67 Tier 4f
212 kW (284 hp) @ 2,200 rpm (rated)
ENGINE Tier 2 Tigercat FPT N67 Tier 2
205 kW (275 hp) @ 2,100 rpm (rated)
ENGINE Non-certified Tigercat FPT N67 Non-certified
212 kW (284 hp) @ 2,200 rpm (rated)
AIR FILTRATION Precleaner and 2-stage engine air cleaner
COOLING Aluminum side by side radiator, oil cooler and charge air cooler
Removable intake debris screen
FAN Hydraulically driven
Automatic variable speed and reversing cycle
FUEL CAPACITY 800 L
DEF CAPACITY 80 L

Hydraulic System

PUMP, MAIN Piston
PUMP, SAW Piston (For disc saw felling attachments only)
PUMP, ATTACHMENT Piston
PUMP, COOLING FAN Piston
PUMP, CLAMP/ACCUM. ARMS Piston
FILTRATION (5) Spin-on, 7 micron full flow
(1) Water absorbing
CYLINDER, HOIST (2) 120 mm (4.7 in) bore
CYLINDERS, STICK/ER (2) 110 mm (4.3 in) bore
CYLINDER, TILT 130 mm (5.2 in) bore
HORSEPOWER CONTROL Electronic speed sensing
All-speed antistall
RESERVOIR 225 L

Undercarriage

TRACK FRAMES R6-152 heavy-duty forestry
Integral track guides/ramp angles
TRACK CHAIN F8 203 mm (8 in) pitch sealed and greased
FINAL DRIVE (2) piston motors with brake valves
Infinitely variable speed
TRACTIVE EFFORT 277 kN
GEARBOX Triple reduction planetary type with brake
FRONT IDLER Hydraulic track adjuster
Spring shock absorber
ROLLERS, UPPER (2) D6D excavator type
ROLLERS, LOWER (9) D6 single/double flange tractor type
SLIDES, UPPER Optional, bolt-on
TRACK SHOE 610 mm (24 in) single/double grouser
Optional 710 mm (28 in) single grouser tri-track
760 mm (30 in) double grouser tri-track
915 mm (36 in) triple grouser tri-track

Brakes

TRACK Friction disc
Automatic spring applied, hydraulic release
SWING Friction disc
Manual spring applied, hydraulic release
