WIDTH | 2 000 mm |
MULCHING SWATH | 1 500 mm |
WEIGHT | 3 330 kg |
TIMING BELTS | (1) 90 mm (3.5 in) width |
MOTORS | (1) Piston, variable displacement |
DIAMETER tip-to-tip | 610-635 mm |
STANDARD | Rotor, open face Bolt-on (30) tool interface |
TOOLS standard | Standard duty, carbide |
TOOLS optional | Impact resistant, carbide Knife, hardened steel |
OPTIONAL | Feed Control Rotor (FCR), bolt-on (30) tool interface |
TOOLS standard | Standard duty, carbide |
TOOLS optional | Impact resistant, carbide Knife, hardened steel |
STANDARD | Bolt-in replaceable wear liner Adjustable skis with carbide hard facing Anvils with carbide hard facing Smooth, open face rotor with standard duty bolt-on tools 65° Bi-directional wrist (hydraulic) Pin on rake |
OPTIONAL | Fixed wrist |
